Double Worm Slewing Drive WED21

What is Double Worm Slewing Drive WED21?

The Double Worm Slewing Drive WED21 is a high-performance rotational drive system engineered to provide robust torque transmission and reliable rotational motion for heavy-duty applications. This drive system integrates a double worm gear configuration, where two worms simultaneously drive the worm wheel, resulting in superior torque output and enhanced holding torque capabilities. Designed for heavy machinery and complex systems that require precision, durability, and high load-bearing capacity, the WED21 is an ideal solution for industries such as construction, mining, renewable energy, marine, and industrial automation.

The WED21 slewing drive is specifically designed to offer increased output torque, axial and radial load capacity, and tilting moment torque, making it suitable for demanding applications that require high reliability under harsh operating conditions. Whether used in turntables, cranes, or any other heavy machinery requiring precise rotational movement, the WED21 provides powerful performance without sacrificing efficiency or durability.

This drive system features a self-locking function, preventing unwanted movement when the drive loses power, ensuring safety during operation. Furthermore, the WED21's high-quality construction, including its sealed casing and heavy-duty bearings, ensures longevity and resistance to the elements, even in the most challenging environments. When mounted, the WED21 slewing drive offers a solution that supports complex machinery with precision, efficiency, and long-lasting performance.

Features of Double Worm Slewing Drive WED21

The WED21 Double Worm Slewing Drive comes equipped with a range of features that elevate its performance, precision, and reliability. Below are the standout features that make the WED21 an ideal choice for demanding applications:

1. High Output Torque and Holding Torque
   The WED21 offers an impressive output torque of 48 kN·m, significantly higher than the WED17 series. The holding torque of 179.8 kN·m ensures that the system can maintain position even under substantial external forces. This increase in torque capacity makes the WED21 suitable for use in large-scale industrial machinery and heavy equipment that require substantial rotational force.

2. Enhanced Axial and Radial Load Capacity
   The WED21 is capable of handling greater axial and radial static loads compared to its predecessor, the WED17. With a static axial rating of 1598 kN and a static radial rating of 640 kN, the WED21 can support much heavier loads. This enhanced load capacity makes it suitable for applications such as cranes, excavators, and other heavy-duty machines that require high strength and stability.

3. Self-Locking Functionality
   One of the most critical features of the WED21 is its self-locking function, which ensures that the drive remains secure and prevents unwanted rotation when there is a loss of driving power. This safety mechanism is essential for applications that require high safety standards, such as heavy cranes, wind turbines, and offshore rigs.

4. Dual Worm Drive for Increased Efficiency
   The WED21 employs a double worm gear configuration, which results in increased efficiency and power transmission. This dual worm drive design not only enhances torque output but also improves overall system performance by reducing the load on each individual worm, making the system more durable and efficient.

5. Sealed Protective Housing
   Like other high-performance slewing drives, the WED21 is encased in a sealed protective housing that shields the internal components from dust, moisture, and other contaminants. This sealed design ensures the drive can withstand harsh environments, including those exposed to high humidity, dust, and extreme temperatures. The WED21 is suitable for both indoor and outdoor use, making it versatile for various industrial applications.

6. High Precision and Tracking Accuracy
   The WED21 features a tracking precision of ≤0.1°, ensuring high accuracy in rotational positioning. This is particularly crucial in applications that require precise movement, such as wind turbine rotation, telescope platforms, and positioning systems in aerospace or defense applications.

7. Dual Row Ball Bearing for Increased Load Capacity
   The WED21 is equipped with a dual-row ball bearing (eight-point contact ball series), which improves its axial and radial load capacity. This bearing type ensures that the slewing drive can handle significant load variations while maintaining stable operation, especially in heavy machinery where both axial and radial forces are common.

8. Optimized Gear Ratio
   The WED21 offers a gear ratio of 90:1, providing a balanced combination of high torque and speed. This gear ratio is optimized for heavy-duty applications, delivering the right amount of torque without compromising the speed of the system. The 90:1 ratio is suitable for applications that require a slower, more controlled movement, such as cranes and turntables.

9. Heavy-Duty Construction
   Weighing 195 kg, the WED21 is a heavy-duty slewing drive designed to withstand intense forces. The substantial weight reflects its robust construction, designed to ensure durability and reliability even under the most demanding conditions.

Applications of Double Worm Slewing Drive WED21

The WED21 Double Worm Slewing Drive is designed for use in a variety of demanding applications where high torque, high load-bearing capacity, and precise rotational movement are required. Below are the key industries and applications where the WED21 is commonly used:

1. Heavy Machinery and Equipment
   The WED21 is ideal for large-scale construction and mining equipment such as cranes, excavators, and loaders. These machines often require high torque to lift and move heavy loads, and the WED21 slewing drive provides the necessary power to perform these tasks efficiently. The slewing drive's enhanced axial and radial load capacity makes it suitable for the heavy-duty requirements of these machines.

2. Renewable Energy – Wind Turbines
   In the renewable energy sector, the WED21 is used in wind turbine systems, where it helps to rotate the turbine nacelle to optimize its exposure to the wind. The slewing drive's self-locking feature ensures that the turbine remains stationary when not in operation, preventing unwanted movement in high-wind conditions.

3. Marine Applications
   The WED21 is suitable for marine applications, such as positioning and rotating cranes on ships, offshore drilling platforms, and winches. Its sealed design makes it resistant to saltwater corrosion and other harsh marine conditions. Additionally, the WED21’s high torque output makes it suitable for heavy marine lifting equipment.

4. Aerospace and Defense
   In aerospace and defense applications, the WED21 is used in systems that require precise rotation, such as radar systems, antenna positioning, and satellite dishes. The slewing drive’s high precision and reliability are critical for systems that must operate without fail in sensitive and high-stakes environments.

5. Industrial Automation
   The WED21 is often found in industrial automation systems that require reliable rotational movement, such as robotic arms, conveyor systems, and automated assembly lines. Its ability to handle heavy loads and provide smooth, controlled movement makes it a valuable component in automated manufacturing.

6. Material Handling
   In the material handling industry, the WED21 slewing drive is used in turntables and rotating platforms that manage large, heavy items. The slewing drive’s ability to support axial, radial, and tilting forces ensures that material handling equipment operates efficiently and safely, even under heavy loads.

7. Offshore and Oil & Gas
   The WED21 is well-suited for offshore drilling rigs and other oil and gas equipment that require high torque and precise movement. Its self-locking capability and heavy-duty construction make it a reliable choice for offshore environments, where equipment must perform under challenging conditions.

How to Customize Double Worm Slewing Drive WED21

Customization of the WED21 Double Worm Slewing Drive ensures that the drive system is perfectly suited to the unique needs of any application. Several factors can be adjusted to optimize the WED21 for specific operational requirements:

1. Torque and Load Capacity
   The WED21 comes with a standard output torque of 48 kN·m, but depending on the application, the torque and load-bearing capacities can be customized. For heavier applications, higher torque options can be selected, ensuring that the slewing drive can handle greater load requirements.

2. Gear Ratio
   The WED21 comes with a standard gear ratio of 90:1. However, depending on the speed and torque requirements, the gear ratio can be adjusted to provide either more speed or more torque, ensuring that the drive matches the operational needs.

3. Sealing and Protection
   Custom sealing options can be selected based on the environmental conditions the slewing drive will be exposed to. For applications in dusty or corrosive environments, enhanced sealing options can be chosen to provide additional protection against moisture, dirt, and other contaminants.

4. Bearing Selection
   Different bearing types can be chosen to optimize the slewing drive’s performance for specific load conditions. For applications involving higher radial or axial loads, custom bearings can be specified to ensure that the drive system performs reliably under these conditions.

5. Mounting and Configuration
   The mounting and installation configuration can be tailored to fit the specific machinery or platform. Custom mounting options ensure that the WED21 integrates seamlessly into different applications, whether used in cranes, wind turbines, or industrial robots.

Price Factors for the Double Worm Slewing Drive WED21

The price of the WED21 Double Worm Slewing Drive is influenced by several factors:

1. Torque and Load Rating
   Higher torque and load-bearing capacities generally result in a higher price due to the increased material and engineering requirements needed to accommodate these specifications.

2. Customization Features
   Custom features such as specialized gear ratios, bearings, and sealing options will add to the cost of the slewing drive.

3. Production Volume
   Bulk orders may lead to price reductions, as economies of scale can be applied during manufacturing. For large-scale projects or long-term orders, suppliers may offer discounts based on the quantity required.

4. Material Quality and Durability
   The choice of materials used in the construction of the WED21 slewing drive can impact the cost. Drives designed for use in extreme environments or those requiring advanced corrosion resistance, such as marine or offshore applications, may cost more due to the use of specialized materials like stainless steel or corrosion-resistant coatings.

5. Lead Time
   Customization and specific requirements may result in extended lead times. If a fast turnaround is needed, this could also increase the price due to expedited production processes. Custom designs with specialized features may also require additional engineering, which can affect the final cost.

6. Sealing and Protection Features
   Enhanced sealing options, such as double sealing systems, waterproofing, and dustproofing, increase the cost of the WED21. These features are particularly important in applications where the slewing drive is exposed to harsh environmental conditions, such as offshore oil rigs or mining operations.

7. Bearings and Precision Features
   The addition of higher-end bearings, such as dual-row ball bearings or specialized thrust bearings, can increase the price. Similarly, precision features, such as high-accuracy tracking systems, will add to the overall cost of the drive system.

8. Supplier and Brand
   The reputation and expertise of the manufacturer can also influence the price. Established and reputable brands may charge a premium for their products, owing to their proven reliability, customer support, and long-term performance. However, some suppliers may offer competitive pricing without compromising on quality, especially when offering value-added services such as technical support and product warranties.

Lyra Drive is a Professional Double Worm Slewing Drive Manufacturer

Lyra Drive is a recognized leader in the field of slewing drives, offering a comprehensive range of products, including the Double Worm Slewing Drive WED21. With years of experience in the design and manufacture of high-quality slewing drives, Lyra Drive specializes in delivering reliable and efficient solutions tailored to the specific needs of its clients.

At Lyra Drive, the focus is on innovation, quality, and customer satisfaction. The company has a dedicated team of engineers and designers who work closely with clients to provide custom solutions for even the most complex applications. Lyra Drive is committed to using only the highest quality materials and the latest technology to produce slewing drives that meet the most stringent industry standards.

As a professional manufacturer, Lyra Drive understands the importance of delivering products that are not only functional but also durable and cost-effective. The company's slewing drives are built to withstand the toughest conditions and provide years of reliable service. Whether you need a standard slewing drive or a customized solution, Lyra Drive is equipped to meet the demands of your industry.

Additionally, Lyra Drive offers comprehensive support services, including product installation, maintenance, and technical assistance. This commitment to customer satisfaction ensures that clients can rely on Lyra Drive for ongoing support and guidance throughout the lifecycle of their slewing drive systems.

Lyra Drive's products are widely used in industries ranging from construction and heavy machinery to renewable energy and marine applications. With a strong reputation for performance and quality, Lyra Drive continues to be a preferred supplier for customers worldwide seeking high-quality slewing drives.

Conclusion

The Double Worm Slewing Drive WED21 represents a significant advancement in slewing drive technology, offering enhanced output torque, higher load-bearing capacity, and precise movement for demanding applications. Its dual worm configuration ensures efficient power transmission and increased torque, while its self-locking feature provides safety and security during operation. Designed for use in heavy machinery, renewable energy, marine, and industrial applications, the WED21 is a versatile and durable solution that can handle the toughest challenges.

Customization options allow the WED21 to be tailored to specific needs, ensuring optimal performance in a wide range of environments. With a robust design, high precision, and the ability to withstand harsh conditions, the WED21 is a top choice for industries that require reliability and strength.

Lyra Drive, a professional slewing drive manufacturer, provides high-quality, customizable solutions to meet the diverse needs of its clients. Whether you're looking for a standard WED21 slewing drive or a tailored solution for a specialized application, Lyra Drive offers the expertise and experience necessary to deliver the right product for your needs.

Investing in a Double Worm Slewing Drive WED21 ensures that your machinery will operate efficiently, safely, and reliably, even under the most challenging conditions.
